TS0718N30-60
- 8 channels integrated: Modular rack‑mount design with a unified DB15 communication interface.
- Includes filament power supply (Fila)
- arc discharge power supply (Arc)
- extraction power supply (Ext)
- and puller power supply (Puller).
- Output ripple: ultra‑low ripple at mV level.
- Long‑term stability: 0.01% per hour (after 0.5‑hour warm‑up).
- External accelerator power supply (Accel)
- suppressor power supply (Supp)
- deflection power supply (Ski)
- and other protection devices.
TS0708
- Main lens source: ~7000 V @ 2 mA
- Bipolar deflection source: ±1000 V to ±4000 V
- Retarding field source: –1500 V to 0 V
- High‑precision current source: 0–2 A / 25 V
- Ripple and noise: better than 20 ppm (0.02–50 Hz)
- Adjustment resolution: voltage step 0.01 V， current step 0.1 mA
- Stability: ppm‑level ultra‑low drift across all channels
- Standard rack‑mount form factor
TESC7080-C0021
- +24V DC input
- Bipolar output with 20 ms polarity switching
- Smooth zero - crossing
- Analog control / RS232 control / USB control /Ethernet control
- In - situ capacitance detection range: 2 pF to 30 nF
- In - situ capacitance detection rate: 10 times per second (within 1 s)
TIE0085
- AC coupling bandwidth: 1 Hz to 2 MHz
- DC input voltage: ±10 kV
- AC output voltage: ±10 V
- Measurable ripple: 5 mVp‑p minimum
- Ripple attenuation ratio: better than 0.95 @50 Hz to 2 MHz
TIE0026
- AC coupling bandwidth: 1Hz-2MHz
- Input voltage DC: 0±60kV
- Output voltage AC: 0±5.5V
- Measurable ripple: > 2mV
- Attenuation ratio: 0.95@1Hz-2MHz
- Input impedance: > 1GΩ
- Output impedance: 50Ω
TXF1280
- 160kV，225kV，320kV，and 450kV are optional
- 1.8kW，3kW，4kW，and 4.5kW are available for selection
- Built-in PFC circuit
- Integrated dual-filament power supply
- Solid-state packaging
- Standard configuration includes USB，Ethernet
- and RS-232 interfaces
- CE Certification
TRC2020-CKH
- Control Signal: 0~10V corresponds to power 0~rated
- Display Status: High voltage on/off， voltage/current
- high voltage status， etc.
- Control Signal: High voltage on/off， voltage/current
- Control Distance: 1.5m (customizable for longer distance)
- Temperature: -25~40°C
- Humidity: <85%
- Matching Model: TRC2020 (Typical)
TNP5050
- Input Voltage -10kVDC
- Output Voltage 375VDC
- Output Power 10kW
- Over-current，over-voltage，over-temperature，and output short-circuit protection
